Turbo Parts No.:1270-988-1107, 1270-970-1107
OE No.:61091017409 / 61.09101-7409 / 07W145701P
Turbo Model:B2G
Turbo Brand:BORGWARNER
Car Application:VW Caminhões Constellation - 18.260 / 18.320 / 26.260 / 26.320 / 27.260 / 30.320 / 31.320 / 33.260 MAN D0836 Diesel 2023 - Ônibus / Micro-Ônibus Chassis Volksbus - 17.260 / 18.320 / 22.260 MAN D0836 Diesel 2023 -
JACK ID:2-00-1827X
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
