Turbo Parts No.:1000-970-0257, 1000-970-0258, 1000-970-0305, 1000-970-0329, 1000-970-0330, 1000-970-0334, 1000-970-0386, 1000-970-0389, 1000-970-0390, 1000-970-0396, 1000-970-0438, 1000-970-0439, 1000-970-0440, 1853-970-0058, 1853-970-0101
OE No.:JG0Q-9G438-CB JB3Q-9G438-AA
Turbo Model:B03V-R2S
Turbo Brand:BORGWARNER
Car Application:Ford Passenger car 2.0 TDI 2017
JACK ID:2-00-1784BX
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
