Turbo Parts No.:AL-2017, 1700-200-002
OE No.:A4710907180;A4720901880;A4720902880;A4710907680
Turbo Model:S410
Turbo Brand:BORGWARNER
Car Application：Freightliner Cascadia Truck (Class 3-8) Detroit Diesel DD15 14.8L 461KM/339kW / 568KM/417kW 2015 – 2021
JACK ID:2-00-3221X
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
