Turbo Parts No.:49189-07803, 49189-07802
OE No.:8201035986, 14411-00Q1K, 8200939131
Turbo Model:TD04HL-20TK32S-VG
Turbo Brand:MHI
Car Application：Renault / Nissan Laguna III / Navara Pathfinder 3.0 dCi V9X 2008-2010 Infiniti QX70 3.0d AWD 2013
JACK ID:5-00-3168
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
