Turbo Parts No.:1631-970-0008, 1631-970-0054, 1631-970-0063
OE No.:18900-5AY-H011-M4, 18900-5AY-H012-M4, 18900-5AY-H013-M4
Turbo Model:B01G
Turbo Brand:BORGWARNER
Car Application:Honda Civic Fit 1.0 VTEC 130HP Gasoline 2016
JACK ID:2-00-1598X
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
